DESCRIPTION
Satellite
A satellite is connected to pressurized water, a number of chemicals and, depending on the model, compressed air.
Using a satellite it is possible for one operator to rinse, foam or disinfect (depending on model).
Pos
Description
1
Inlet air
2
Inlet water
3
Air regulator
4
Injector system
5
Suction tube chemical
6
Dosing valve chemical
7
Function selector
8
Outlet
