System Sensor MASS12LO User Manual

D900-06-00 4 I56-750-57
© System Sensor 1996
1. Screw plate to box with screw E.
2. Complete field wiring. (See Fig. 3,
4, 5, and 6)
3. Screw sounder or sounder/strobe
to plate with screw A.
4. Fill remaining holes with screw B.
A78-2517-01
1. Screw strobe to plate with
screw C.
2. Complete field wiring.
3. Screw strobe plate to box with
screw A.
A78-2516-00
1. Plaster ring should be properly mounted to electrical box
with screws supplied with box.
2. Screw plate to plaster ring with screw G.
3. Complete field wiring. (See Fig. 5, 7, and 8)
4. Screw sounder/strobe to plate with A.
5. Fill remaining holes with screw B.
A
A
B
B
G
G
MA 12/24
MP-SF
Plaster
Ring
Standard
Backbox
A78-1137-11
1. Complete field wiring.
2. Screw plate sounder to Box
with screw F.
A78-1137-08
C
F
F
C
MP-F
MA 12/24D
D
D
BB-D
A78-2515-00
A78-2514-00
Figure 9. Strobe surface mount:
1. Complete field wiring.
2. Screw sounder/strobe to box
with screw A.
3. Fill remaining screw holes with
screw B.
Figure 10. Sounder/strobe surface mount:
MA-12/24D
A
B
B
A
Signal Strobe
Standard
Backbox
1. Complete field wiring.
2. Screw strobe to box with screw A.
3. Fill remaining holes with Screw B.
B
A
A
B
Signal Strobe
Standard
Backbox
TOP
MP-SF
MA-12/24D
B
B
STANDARD
BACKBOX
A
A
E
E
MP-SF
Signal Strobe
TOP
STANDARD
BACKBOX
C
C
A
A
Figure 11. Sounder or sounder/strobe semi-flush
mount:
Figure 12. Strobe semi-flush mount:
Figure 13. Sounder flush mount (deep box required): Figure 14. Sounder or sounder/strobe semi-flush
mount with plaster ring:
