SystemAir NOVA drive 370

Systemair NOVA drive 370
|
15
New info features
ModbusAddress 0x4F RW Address used in Modbus. Default is 7
AlarmLog 0xC0 R Last 4 FaultContent alarm codes
ModuleTemperature 0xC1 R Temperature of the module in [ºC]
MceStatusFlags 0xC2 R Status flags of the motor control software for internal usage
MceFaultFlags 0xC3 R Fault flags of the motor control software for internal usage
PCBTemperature 0xC4 R PCB temperature in [ºC]
WarningContents 0xC5 R Warnings, which each bit as set for each according to Table 9
SpeedSetScaled 0xC7 R Reference speed in [10*rpm]
Dip1 0x110 R Dip 1 value, 0 (off) or 1 (on)
Dip2 0x111 R Dip 2 value, 0 (off) or 1 (on)
Dip3 0x112 R Dip 3 value, 0 (off) or 1 (on)
Dip4 0x113 R Dip 4 value, 0 (off) or 1 (on)
Dip5 0x114 R Dip 5 value, 0 (off) or 1 (on)
Guard in 0x115 R Rotor guard value 0 or 1
Test running 0x116 R 1 when test is running, 0 otherwise
Speed external 0-10V 0x117 R 0 - 4095 speed input
Trimmer 0-10V 0x118 R 0 – 4095 trimmer input
Extended SW version
FrontendVersion 0x320 –
0x333
R Frontend software version C string.
BackendVersion 0x334 –
0x347
R Backend software version C string.
Table 4 – Modbus registers
10.5 Normal operation
Write the speed reference in SpeedSet between 0 and 1000 (0-100%). Note that the conversion from SpeedSet to
rpm speed is non-linear. The reference in rpm can be read using register SpeedSetScaled. The minimum and maximum
speed can be read in registers MinSpeed and MaxSpeed.
Start the motor by setting Operation to 1. Stop it by setting it to 0. You can change the speed while the motor is run-
ning.
If communication with the device is stopped, a warning will appear after 10 seconds but the motor will keep running.
Faults and warnings can be reset by setting operation Bit 3.
