6.7Hotwaterheater
Thehotwatercoilislocatedafterthefan.Thecoilismountedforeasyconnectionthroughtheshortside
oftheunit.Atthesametime,itisdesignedinsuchawaythatitiseasytoaccessthepipeconnections.
Thematerialiscopperpipingwithaframeofgalvanizedsheetsteelandaluminumns.
Thecoilhasaventingnippleandoneimmersionthermostatasfrostguard.Ifthetemperaturedropsand
thereisariskoffreezing(outletwatertemperaturebelow8°C)thewaterowismaintained(themagnetic
valvewillopenfully),thefanstopsandtheoutdoorairdamper,accessory,closesinstantaneously
Fig.10Waterregulation
APump,secondarycircuit
BNon-returnvalve
CValve-actuator+watervalve(accessories)
DPumpprimarycircuit
Thegureshowsapossiblesolutionfordesigningthewaterregulation.
(a)using2wayvalveand(b)using3wayvalve.
