SystemAir TA Series User Manual

8Controlpanel
8.1Generalinformation
ThecontrolpanelisdeliveredconnectedtotheCorrigocontrolunitsituatedintheelectricalconnection
box.Cablelengthis10m.Incasethecontrolpanelneedstobedetachedfromthesignalcableitis
possibletoloosenthewiresonthebackofthecontrolpanel(gure13).
Asetofself-adhesivemagnetstripsareincludedinthepackagetofacilitateinstallationonametalsurface.
8.2Dimensions
Fig.12Controlpaneldimensions
Position
Dimensions(mm)
A115.0
B94.0
C
26.0
D
c/c60.0
E50.5
TA450-4500Installationinstructions
132615
24
SystemairSverigeAB
