Mainmenuitem
Sub-menuitem1Sub-menuitem2
Explanations
→Frost
protection
Active
Setpshutdown:
25.0°C
P-bandactive:
5.0°C
P-bandactive5°Cmeansthat
thefrostprotectioncontroller
willstartoverridingtheheating
outputwhenthefrostprotection
temperatureislessthan5
degreesabovethesetfrost
alarmdefaultalarmlimitis7°C
Faststop
atfrost
protection
alarm
Yes
Setthefaststopoftheunitin
caseoffrostprotectionalarmto
YesorNo.
→Controlflow
AlternativelyPressure
controlifchoseninthe
congurationoftheunitfrom
factory
Flowcontrol
SAF
P-band:
10000.0m³/h
I-time:10.0
sec
Min.output:
0%
SetP-band,I-timeandMin.
outputforthesupplyair
fanwhentheunitcomes
conguredasFlowcontrol
fromfactory.Alternatively
Pressurecontrolifthat
congurationischosen
Flowcontrol
EAF
P-band:
10000.0m³/h
I-time:10.0
sec
Min.output:
0%
SetP-band,I-timeandMin.
outputfortheExtractair
fanwhentheunitcomes
conguredasFlowcontrol
fromfactory.Alternatively
Pressurecontrolifthat
congurationischosen
→Alarm
settings
→Alarmlimits
Setthealarmlimitsandallowed
deviationsforthedifferent
functions
→Alarmdelays
Setthealarmdelaysand
alloweddeviationdelaysforthe
differentfunctions
→Restorealarm
Resettheservicealarm(lter
alarm).
Restorefactory
settings:No
Restoreuser
settings:No
Inthismenu,itispossibleto
restoreallparameterstotheir
factorysettingsortotheuser
settingstheyweresavedas
earlier.
SelectYesorNo
TopvexSR/TR03,SR/TR04,SR/TR06OperationandMaintenanceInstructions
206902
18
SystemairAB
