the t.bone EM-9900
Specifications subject to change without notice!
Diagrams:
Introduction:
Thank you for purchasing the EM-9900 microphone.
Warning:
Never remove the screen holding the capsule, as this can
damage the microphone!
Caution:
Do not drop your microphone! This can cause severe damages!
Maintenance and cleaning:
When the microphone is not in use, take it out of its clamp and
place it in its case.
Clean with wet cloth only.
Specifications:
Type: condenser
Frequency response: 30Hz to 20kHz
Polar Pattern: hyper cardioid / lobar
Sensitivity: -37dB, 12,6mV/Pa
Output impedance: 200 ohms
Max. SPL (@1% THD): 130dB
Power: 9-52V phantom power
Power consumption: 2mA
Audio connection: 3-pin XLR
Dimensions: 21mm x 431,5mm
We’d like to thank you for your confidence in the product and
hope that you will enjoy your new microphone.
20
10
0
-10
-20
20
50
100
500
1K 10K 20K
200
30K2K
5K
-25
25
0
30
60
90
120
150
180
210
240
270
300
330
R-110105 KR
