14. ORDERING SPARE PARTS












10.1. CLAMP SUPPORT <168 5500896
ItemPart No. Name Size/Type Std./Manuf. Qty
13500903 Clamp frame 2
23500904Fastening plate 2
39214010 Screw M8 x 25 8.8
DIN7984
8
49016007 Set screw M8 x 812.9
DIN913
4
54280104 Clamp holder pin 4
69018037Parallel pin Ø6m6 x 32 DIN6325 4
79018219 Spring pin Ø6 x 30 DIN14812
1 2 3
1. Part number 2. Descripon 3. Quanty



  
  
  
  
  
