T2 LUKE II - INSTALLING THE KEYPAD LIGHT; Drill Mounting Holes

Luke
®
II Keypad Lighting Installation Guide
1
T2 Systems, Inc. | T2systems.com
INSTALLING THE KEYPAD LIGHT
T2 Systems has developed a new LED light fixture to illuminate the keypad of your Luke
®
II multi-space
pay station. The light is designed to help the consumer make an easier keypad selection, especially at
night if the unit is installed in a dimly lit location.
This document will guide you through the steps to install the light above your keypad. There will be some
drilling involved on the cabinet cast and door to affix the lighting assembly.
Drill Mounting Holes
Tools and Materials Required
 Drill
 Drill bits: 9/64in, 3/8in, 1/2in
 Round file (for removing burrs)
 Felt pen (for marking drill location)
 Cardboard sheet, approximately 9x10in (to prevent scuffing the decal and keypad)
 Cloth rag or paper towels to catch drill filings
 Masking tape
 Mask template (see Appendix A)
 Zinc-rich paint:
□ Contains more than 65 percent zinc powder, for restoring the zinc undercoat protection
after drilling the door:
 Brite Zinc – aerosol spray
 Rust-oleum – professional galvanizing compound spray
 Rust-oleum – automotive galvanizing compound spray
 Marine grease (we recommend Ultra Lube
®
marine grease or Lucas Oil
®
marine grease):
□ For protecting the aluminum alloy cast after drilling
 Q-tips (for applying grease)
 Protective gloves
 Safety goggles
Parts
 Drill templates:
□ 160.0194 – Drill Template, Keypad Light – Front Cast
□ 160.0195 – Drill Template, Keypad Light – Door Inside
