12
SERVOS AND ACCESSORIES
SERVOS
GPMM1190 ElectriFly
®
ES18 1.8G Micro Linear Servo
TACL0324 Tactic TR324 3-Channel Receiver
TACL0624 Tactic TR624 6-Channel Receiver
TACL0421 Tactic TR421 4-Channel Rx Control Board
TACM0021 Tactic TSX21 Linear Servo Actuator
FUTM4503 FPC10M Micro Servo/Battery Connector
FUTM4504 AEC-29 Micro Y-Harness 75mm, 3 in.
BATTERIES AND CHARGERS
FUGP7308 Fuji
®
AA Alkaline Batteries (8)
HCAA6309 Flyzone
™
LiPo 3.7V 130mAh Micro RTF Battery
ELECTRONIC SPEED CONTROLS*
FPWM0206 FlightPower
®
6A LiPo BL ESC BEC
FPWM0210 FlightPower 10A LiPo BL ESC BEC
GPMM1800 SS8 Brushless 8 AMP ESC
GPMM1810 SS12 Brushless 12 AMP ESC
* Input connectors on each ESC would need to be replaced with the appropriate micro connector
SPECIFICATIONS
TTX402 4-Channel Micro Transmitter
Channels 4
Frequencies 2.403 – 2.480GHz
Modulation FHSS spread spectrum
Input power Five “AA” alkaline, NiCd, or NiMH cells (4.0 – 8.0V, not included)
Output power
<
3mW
Power indicator Red LED, with 4.5V low voltage alarm
Audible tones Low voltage alarm, trim lever adjustments, stick mode setting
Servo reversing All channels
Stick modes 3-channel and 4-channel configurations
Built-in LiPo charger Battery type and size: For external 1S LiPo battery
Charge jack: Micro LiPo connector
Output voltage: 3.7V nominal, 4.0V maximum
Charge current: 250mA
Backup safety timer: 45 minutes
Trims Digital for all channels
TACJ2402 Mnl.indd 12TACJ2402 Mnl.indd 12 4/20/2011 9:51:29 AM4/20/2011 9:51:29 AM
