This document provides installation, usage, and maintenance instructions for the TaiShan Training Type Parallel Bar, model TQ2001, manufactured by Shandong Taishan Sports Equipment Co., Ltd.

Function Description:

The TaiShan Training Type Parallel Bar TQ2001 is designed for both competition and training purposes in gymnastics. It features a robust construction with a height-adjusting tube that utilizes chrome-plated technology for wear resistance. The design emphasizes convenient installation and secure operation, with firmly clamped locking parts ensuring the bar's adjustability, safety, and stability during use.

Important Technical Specifications:

Dimensions:
- Length (L): 350 cm
- Width (W): 167 cm
- Height (H): Adjustable from 160 cm to 210 cm
Bar Width Adjustment: Steplessly adjustable from 42 cm to 62 cm.
Bar Height Adjustment: Adjustable from 160 cm to 210 cm, with adjustments in 5 cm increments.
Maximum Load: 500 Kg.
Components:
- A-Base: 1 pc
- B-column: 4 pcs
- C-bar: 2 pcs
- D-hexagon head bolt: 12 pcs
- E-plain washer: 12 pcs
- F-inner hexagon head screw: 4 pcs
- G-pad: 4 pcs
- H-adjusting gasket: 8 pcs
- I-24 single ended wrench: 1 pc
- J-6mm internal h-wrench: 1 pc
- K-3mm internal h-wrench: 1 pc
- L-2.5mm internal h-wrench: 1 pc
- M-PB adjustment wrench: 1 pc

Usage Features:

The parallel bar is intended for gymnastic use only and must be operated under the guidance and supervision of professionals. It is strictly for indoor use. Children under 10 years of age are not permitted to use the equipment. The bar is designed for single-person use at any given time, with a maximum load capacity of 500 Kg.

Installation Steps:

Place the base (A) on a level, solid floor.
Use the I-24 single-ended wrench to fix the A-Base and B-columns together using D-hexagon head bolts and E-plain washers. Ensure the trademark column is positioned on the diagonal side.
Fix the C-bars to the B-columns using H-adjusting gaskets, G-pads, and F-inner hexagon head screws.
- Note on Gaskets: It is recommended to install one adjusting gasket on each column. Each column is supplied with two standard gaskets. After tightening the hexagon socket screw, there should be no obvious obstruction during the spacing adjustment between the horizontal bar and the column. Shaking the horizontal bar in the vertical direction should confirm no obvious open movement between the horizontal bar and the column. If open movement occurs, remove the adjusting gasket. If the horizontal bar spacing adjustment is significantly obstructed, increase the adjustment gaskets to two pieces per column.

Adjustment Instructions:

To adjust the height and width:

Raise the handle of the lock gear component upwards.
Adjust the inner tube to achieve the desired height.
Simultaneously rotate the lock gear component and the elbow to adjust the width.
Ensure that the height of the four regulating tubes and the width between the two horizontal bars are coordinated.

Safety Precautions:

Always check all parts of the equipment for good condition and ensure they are firmly locked before use. Replace any damaged parts immediately.
Install and use the equipment with a special protective mat.
Stop using the equipment immediately if any abnormal sound or loose parts are detected.
Do not make adjustments while the equipment is in use.
Warm up before using the equipment and stop if you feel unwell.
Avoid knocking or scratching the equipment with hard objects.

Maintenance Features:

Regular Checks: Periodically inspect all connecting parts for looseness or detachment. Tighten or replace them promptly to ensure safe use.
Cleaning:
- For the bar surface, gently wipe it with a towel dipped in clean water when dirty.
- Wipe the surface of the equipment with a neutral detergent and clean water.
Professional Maintenance: The equipment should be checked and maintained by professionals after one year of use.
Lubrication:
- Apply lubricating oil to one inner column and three locking pipes monthly.
- Drag the shaft and five stud bolts to ensure the handle turns flexibly for adjustment and locking.
- It is strictly prohibited to apply lubricating oil to other parts.
- Note: Special liquid lubricating oil should be used. Vegetable oil can be used as an alternative if special lubricating oil is unavailable.
Lock Parts Maintenance:
- If the lock parts become loose, lift one handle.
- Use the L-Allen wrench to remove the four socket head screws on both ends.
- Hold one handle and use the PB adjustment wrench (M) to adjust the two sinistral lock nuts and five right-lateral lock nuts.
- Lock the parts, ensuring the socket head cap screw is tightened onto the lock nut in the card slot.
- Finally, return the handle to its original position.

Warranty Information:

Base: 3 Years
Column: 3 Years
Bar: 1 year or 100,000 frequency
Foot Margin: 1 year
Lock Part: 1 year
Exclusions:
- Damage caused by improper use or maintenance is the user's responsibility.
- Surface damage (scratches or bumps) is not covered by the warranty.
Post-Warranty Service: Free technical support and paid maintenance services are available for the equipment beyond the warranty period.
