TM8100/TM8200 Service Manual Transmitter Fault Finding (25W) 331
© Tait Electronics Limited June 2006
Figure 12.4 Test points for checking the 9V supply, the forward and reverse RF power, and the
inhibiting of the transmitter
DIRC TOP CAN
IF TOP CAN
VCO TOP CAN (UHF ONLY)
D TX INH
TEST POINT
TX INH
TEST POINT
REV PWR
TEST POINT
FWD PWR
TEST POINT
GND TEST POINT
9V0 TX TEST POINT
