TM8100/TM8200 Service Manual CODEC and Audio Fault Finding 389
© Tait Electronics Limited June 2006
Figure 13.4 Circuitry under the CDC BOT can
LO2 BOT CAN
CAN FOR
DIGITAL
BOARD
JUNCTION OF R218 AND IC204CDC AUD TAP OUT
