Tait TM8105 Service Manual

Ref. IPN Description Ref. IPN Description
Ref. PCB Circuit Ref. PCB Circuit
Ref. PCB Circuit
524 Installing a Remote Kit TM8100/TM8200 Service Manual
© Tait Electronics Limited June 2006
C1 015-06470-01 Cap Cer 1206 470n X7r 20% 50v
C2 018-14470-00 Cap 0603 4n7 50v X7r±10%
C3 015-07220-08 Cap Cer 1206 2u2 16v X7r
C4 018-13470-00 Cap 0603 470p 50v X7r±10%
C5 018-13470-00 Cap 0603 470p 50v X7r±10%
C6 018-14470-00 Cap 0603 4n7 50v X7r±10%
C7 015-23270-05 Cap 0805 270p 1% 200v Grm40
C8 015-23270-05 Cap 0805 270p 1% 200v Grm40
C9 018-15330-00 Cap 0603 33n 50v X7r10%
C10 015-23270-05 Cap 0805 270p 1% 200v Grm40
C11 015-23270-05 Cap 0805 270p 1% 200v Grm40
D1 001-10000-99 Diode SMD BAV99 D-Sw SOT23
DS1 008-00014-74 LED Hp Red Rang PCB Mtg
D2 001-10000-99 Diode SMD BAV99 D-Sw SOT23
D3 001-10000-99 Diode SMD BAV99 D-Sw SOT23
E1 057-10600-05 Ind 0603 Blm11p600s .5a F/Bead
E2 057-10600-05 Ind 0603 Blm11p600s .5a F/Bead
E3 057-10600-05 Ind 0603 Blm11p600s .5a F/Bead
E4 057-10600-05 Ind 0603 Blm11p600s .5a F/Bead
E5 057-10020-02 Ind 0603 BlM18pg300 Emi Supr
J1 240-10000-11 Conn SMD 18w Skt M/Match
J3 240-00016-00 Conn RJ45 Shld 8P8C LP RA TH
Q1 000-10561-60 XSTR BCX56-16 AF NPN SOT89
R1 038-13100-10 Res 0603 100R 1/10w 1%
R3 038-15100-10 Res 0603 10k 1/10w 1%
R4 038-13100-10 Res 0603 100R 1/10w 1%
R5 038-16100-10 Res 0603 100k 1/10w 1%
R6 038-14220-00 Res 0603 2k2 1/10w 5%
R7 038-15100-10 Res 0603 10k 1/10w 1%
R8 038-13560-10 Res 0603 560R 1/10w 1%
R9 038-13560-10 Res 0603 560R 1/10w 1%
R10 036-02270-10 Res 1206 27.0e 1%
R11 036-02270-10 Res 1206 27.0e 1%
R12 038-13120-00 Res 0603 120R 1/10w 5%
R13 038-16100-10 Res 0603 100k 1/10w 1%
R14 036-05100-01 Res M/F 1206 10k 5%
U1 002-10078-00 IC SMD MC78M05CDT5v Reg0.5a
U2 002-10014-85 IC ADM1485 RS485 Transc S08
220-02123-01 PCB Single Rmt Radio I/F
25.4.2 RJ-45 Control Head (PCB IPN 220-02123-01)
Parts List
Grid Reference List
C1 F2 1B1
C10 M2 1B6
C11 M2 1B7
C2 H2 1D3
C3 J1 1D4
C4 J2 1D5
C5 L2 1D5
C6 L2 1C6
C7 M2 1C6
C8 M2 1C6
C9 N2 1C6
D1 K2 1C4 1D4
D2 K1 1C5 1D5
D3 L2 1D6 1E6
DS1 F2 1B1
E1 L2 1C5
E2 M2 1B6
E3 M2 1D6
E4 L2 1C6
E5 N2 1D6
J1 H2 1D1
J3 N2 1C7
MT1 R2 1B4
Q1 F2 1B1
R1 F2 1B1
R10 L2 1D5
R11 L2 1C5
R12 L2 1C5
R13 L2 1D5
R14 M2 1E6
R2 H2 1D2
R3 G2 1D3
R4 H2 1D3
R5 K2 1D3
R6 J2 1D4
R7 J2 1D4
R8 K1 1D5
R9 L2 1C5
TP2 M1 1B4
U1 D2 1B2
U2 K1 1C4

Tait TM8105 Specifications

General

Brand	Tait
Model	TM8105
Category	Radio
Language	English
