206 Frequency Synthesizer Fault Finding TM8100/TM8200 Service Manual
© Tait Electronics Limited June 2006
Figure 9.10 Synthesizer circuitry under the SYN TOP and VCO TOP cans (UHF radio, top side)
Tx port
Junction of
C541 and R547
Rx port
Q507 Q506 Q508
