TM8100/TM8200 Service Manual CODEC and Audio Fault Finding 401
© Tait Electronics Limited June 2006
Figure 13.10 Circuitry under the CDC TOP can
ITF AUD TAP IN
JUNCTION OF R237 AND R241
JUNCTION OF
R229 AND R232
