Ref. IPN Description Ref. IPN Description
Ref. PCB Circuit Ref. PCB Circuit
Ref. PCB Circuit
540 Installing an Enhanced Remote Kit TM8100/TM8200 Service Manual
© Tait Electronics Limited June 2006
C1 018-16100-00 Cap 0603 100n 16v x7r + - 10%
C2 015-07470-20 CAP Cer 1206 4u7 10% 25V X7R
C3 015-06470-01 Cap Cer 1206 470n X7r 20% 50v
C4 018-13100-00 Cap 0603 100p 50v NPO ±5%
C7 015-27100-08 Cap Cer 0805 X7R 1uF 16V 10%
C9 018-13100-00 Cap 0603 100p 50v NPO ±5%
C10 018-16100-00 Cap 0603 100n 16v x7r + - 10%
C13 018-16100-00 Cap 0603 100n 16v x7r + - 10%
C15 018-16100-00 Cap 0603 100n 16v x7r + - 10%
C17 018-16100-00 Cap 0603 100n 16v x7r + - 10%
C101 018-16100-00 Cap 0603 100n 16v x7r + - 10%
C102 015-07470-20 CAP Cer 1206 4u7 10% 25V X7R
C103 015-07470-20 CAP Cer 1206 4u7 10% 25V X7R
C203 018-13270-00 Cap 0603 270p 50v NPO±5%
C207 018-13270-00 Cap 0603 270p 50v NPO±5%
C209 018-13270-00 Cap 0603 270p 50v NPO±5%
C213 018-13270-00 Cap 0603 270p 50v NPO±5%
DS1 008-00014-73 LED Hp Grn Rang PCB Mtg
J1 240-10000-11 Conn SMD 18w Skt M/Match
J2 240-00016-00 Conn RJ45 Shld 8P8C LP RA TH
J3 240-00016-00 Conn RJ45 Shld 8P8C LP RA TH
R1 038-13120-00 RES 0603 120R 5% 1/10W
R2 038-10000-00 RES 0603 0R
R3 038-15820-10 RES 0603 82k 1% 1/10W
R4 038-15820-10 RES 0603 82k 1% 1/10W
R6 038-15220-10 RES 0603 22k 1% 1/10W
R7 038-15100-10 RES 0603 10k 1% 1/10W
R8 038-15820-10 RES 0603 82k 1% 1/10W
R9 038-13100-10 RES 0603 100R 1% 1/10W
R10 038-15100-10 RES 0603 10k 1% 1/10W
R12 038-16100-10 RES 0603 100k 1% 1/10W
R13 038-16100-10 RES 0603 100k 1% 1/10W
R14 036-13560-10 RES 0805 560R 1% 1/8W
R15 038-15820-10 RES 0603 82k 1% 1/10W
R16 038-15100-10 RES 0603 10k 1% 1/10W
R17 038-15220-10 RES 0603 22k 1% 1/10W
R18 038-13220-10 RES 0603 220R 1% 1/10W
R19 038-14120-10 RES 0603 1k2 1% 1/10W
R20 038-10000-00 RES 0603 0R
R21 038-10000-00 RES 0603 0R
R30 038-13390-10 RES 0603 390R 1% 1/10W
R31 038-13390-10 RES 0603 390R 1% 1/10W
R40 036-00000-01 RES 1206 0R 5% 0.25W
R103 038-12100-10 RES 0603 10R 1% 1/10W
R104 038-15100-10 RES 0603 10k 1% 1/10W
R203 038-13100-10 RES 0603 100R 1% 1/10W
R207 038-13100-10 RES 0603 100R 1% 1/10W
R209 038-13100-10 RES 0603 100R 1% 1/10W
R213 038-13100-10 RES 0603 100R 1% 1/10W
R911 036-00000-01 RES 1206 0R 5% 0.25W
R915 036-00000-01 RES 1206 0R 5% 0.25W
R917 038-10000-00 RES 0603 0R
U1 002-19120-00 IC TS912ID Cmos R2R Opamp
U2 002-12523-17 IC LM317l Reg T0252 0.5a
U3 002-13483-00 IC XCVR RS485 LTD SLEW RATE 3V
219-02882-00 Loom Control Head TMA
219-02950-00 CBL MFX Remote Kit Gnd Lead
220-01720-05 PCB MFX Radio Remote
302-10063-01 Brkt PCB Remote TM8200 Body
302-50002-01 Bung RJ45 MFO
316-06843-00 Pnl Frt Remote TM8200 MF0
346-10030-08 Scrw P/T Wn1412 Kc30x08 Zbc
349-02062-00 Scrw M3*8 T/T P/T ContiR
26.4.2 TMAC34-0T Torso Interface (PCB IPN 220-01720-05)
Parts List
Grid Reference List
C1 1:J2 H7
C2 1:K1 J6
C3 1:D2 H3
C4 1:J1 H8
C5 2:J2 G7
C6 1:K1 J7
C7 1:J2 G7
C8 2:K2 J9
C9 1:K2 G8
C10 1:N2 G9
C13 1:N2 G9
C15 2:L2 H10
C17 2:L2 H8
C102 1:D1 H4
C103 1:E2 D7
C203 1:J2 D6
C207 1:H2 D5
C213 1:H1 D6
DS1 1:F2 J5
D1 2:J2 G4
D2 1:H2 E5
D3 2:H2 G3
J1 1:H2 E3
J2 1:N2 E12
J3 1:L2 G12
J4 1:M2 D9
MT1 1:R2 F12
Q1 2:G2 G4
Q2 2:G2 F5
R1 2:N2 E10
R2 2:J2 G7
R3 1:J1 J6
R4 1:J1 J6
R5 2:H2 G4
R6 1:J1 H7
R7 1:G2 E5
R8 1:J1 J8
R9 2:L2 J9
R10 1:K2 G8
R11 2:G2 F4
R12 1:N2 G9
R13 1:N2 G9
R14 1:F2 H5
R15 2:L2 H9
R16 1:H2 D5
R17 2:L2 H9
R18 1:D2 H4
R19 1:E2 H4
R20 2:L2 J10
R21 1:N2 G10
R22 2:H2 G4
R23 2:G2 G5
R24 2:G2 F5
R30 1:F2 D10
R31 1:E2 E9
R40 2:N2 F11
R103 1:G2 E7
R104 1:G2 E7
R203 1:J2 E6
R207 1:J2 E6
R209 1:H2 E6
R213 1:H2 E6
R820 2:L2 H10
R821 1:N2 G10
R900 1:F2 E9
R901 1:E2 E9
R910 2:J2 E10
R911 2:L2 F11
R912 1:H2 E5
R915 2:M2 G12
R916 2:N2 F11
R917 1:N2 F11
R918 2:M2 G11
R920 1:D2 J4
U1 1:K1 G8
J8
J5
U2 1:D2 J4
U3 1:F2 E8
