11 General Information Tuneup
August 2004© Tait Electronics Ltd
Figure 1.2 Illustration of the face of the test unit
Radio
Rx
Tx / PTT
Speaker
Radio
Load
TOP Mod Audio
Mic Audio
Rx Audio /
SINAD
Tx Audio
Computer
TOP
Off
Hook On
Hook Off
TM8000 only
TM8000
AUDIO OUT
SWITCH
AUDIO IN
SWITCH
SPEAKER
SELECTOR
SWITCH
HOOK
SWITCH
MODE
SWITCH
