TM8100/TM8200 Service Manual Description 31
© Tait Electronics Limited June 2006
Figure 2.6 Components of the control head (1-, 2- or 3-digit display)
B
control-head loom with female-female adapter
I
knob for volume-control potentiometer
C
control-head options board (optional)
J
speaker
D
3 x 8 PT screw (x3)
1)
concealed microphone (optional)
E
control-head board
1!
LCD
F
elastomeric strip (x2)
1@
keypad
G
space-frame
1#
short light pipe
H
front panel assembly
1$
long light pipe
J
B
1^
G
I
H
1)
1&
1#
1%
1$
F
E
1!
3828z_01
D
x3
B
C
E
F
x2
G
H
1)
J
1@
1#
1$
1!
I
