374 Transmitter Fault Finding (25W) TM8100/TM8200 Service Manual
© Tait Electronics Limited June 2006
Figure 12.17 Circuitry under the PIN TOP can, and points for attaching the test lead and test capacitor
(UHF shown)
MOUNTING POINT
FOR TEST
CAPACITOR
SOLDER OUTER
SHEATH TO GND
