1
Ver.: 2.7 05/2006-ENG
RCA 380
Please carefully read the operating instructions before using the machine!
OPERATING INSTRUCTIONS
FIREWOOD PROCESSOR
:
RCA 380 E

Questions and Answers

  • B
    Barbara PerryAug 17, 2025
    Why is the hydraulic oil overheating in my Tajfun Planina Log Splitter?
    • J
      Jean BaileyAug 18, 2025
      If the hydraulic oil in your Tajfun Planina Log Splitter is overheating, several factors could be the cause. First, check the oil level in the reservoir and add more if necessary. The hydraulic oil itself might be worn out, requiring a complete oil change. A clogged oil filter or hydraulic pipes can also lead to overheating, so clean them. Ensure that the splitting cylinder reaches its final position, reversing the cylinders and cleaning the splitting chute if needed. Finally, high outside temperatures can contribute to this issue; consider installing an oil cooler.
  • N
    Nathan VegaAug 20, 2025
    Why is my Tajfun Planina Log Splitter losing power?
    • A
      Adriana OlsonAug 20, 2025
      If your Tajfun Planina Log Splitter is losing power, it could be due to several reasons. Hydraulic oil overheating can cause power loss, so refer to troubleshooting steps for that issue. Insufficient oil in the reservoir can also lead to power loss; check the oil level and add more if needed. Additionally, the machine might be overloaded, so remove any causes of overloading.
  • J
    jhowardAug 22, 2025
    Why is my Tajfun Planina Log Splitter operating so loudly?
    • M
      Michelle MillerAug 22, 2025
      If your Tajfun Planina Log Splitter is operating louder than usual, several factors could be responsible. For RCA 380 models, exceeding the recommended tractor revolution speed can cause increased noise, so adhere to the recommended speed. A clogged filter can also contribute to louder operation, so clean the filter. Insufficient oil in the reduction gear may be the cause, so check the oil level and add more if necessary. For RCA 380 models, ensure the machine is properly connected to the tractor, not just the P.T.O. shaft, or position the tractor perpendicular to the machine. Lastly, a P.T.O. shaft that is not lubricated can cause noise, so lubricate it appropriately.
  • M
    marymooreAug 26, 2025
    Why is my Tajfun Planina Log Splitter consuming so much power when sawing?
    • L
      lcarterAug 26, 2025
      Excessive power consumption during sawing with your Tajfun Planina Log Splitter may be due to a few reasons. The chain may be dull, requiring you to sharpen or replace it. The chain might not be properly tensioned, so ensure you tension the chain correctly. Also, the chain could be covered with resin; clean it using a solvent like Nitro-Solvent or replace it.
  • K
    kerrstephanieAug 27, 2025
    What to do if Tajfun Planina RCA 380 does not react to the sawbar activation handle?
    • A
      Ashley DavisAug 27, 2025
      If your Tajfun Planina Log Splitter doesn't react to movements of the sawbar activation handle, start by checking the machine drive. Ensure the P.T.O. shaft or electric motor is connected and in operation, as the pump and chainsaw drive won't work otherwise. Also, verify the oil level in the tank. If these are fine, the control mechanism might be damaged, requiring repair or replacement.
  • C
    christinagrahamAug 30, 2025
    Why are the hydraulic hoses overheating on my Tajfun Planina RCA 380 Log Splitter?
    • M
      Malik AndrewsAug 30, 2025
      If the hydraulic hoses on your Tajfun Planina Log Splitter are overheating, it could be due to insufficient oil in the hydraulic system; check the oil level and add more if necessary. Another potential cause is worn-out hydraulic oil, which would require you to replace the hydraulic system oil.
  • T
    Tracy BryantSep 1, 2025
    What to do if the electric motor of my Tajfun Planina RCA 380 Log Splitter does not start or shuts down often?
    • S
      Sharon EdwardsSep 1, 2025
      If the electric motor of your Tajfun Planina Log Splitter (RCA 380 E) doesn't start or frequently shuts down, check for damages to power cables or blown fuses and replace/install as needed. The motor protection might be shutting the motor down because the power cable size is not appropriate, or the machine is overloaded.
  • B
    Bobby HerreraSep 4, 2025
    Why is the in-feed conveyor slipping or not operating on my Tajfun Planina RCA 380?
    • S
      Shannon Grant MDSep 4, 2025
      If the in-feed conveyor on your Tajfun Planina Log Splitter is slipping or not operating, it could be that the conveyor belt is not tensioned enough, so tension the conveyor belt. Also, check if there is enough oil in the hydraulic system and add more if necessary.
  • K
    kellerjosephSep 6, 2025
    Why is the discharge conveyor not operating on my Tajfun Planina RCA 380 Log Splitter?
    • N
      Nathan RodgersSep 6, 2025
      If the discharge conveyor on your Tajfun Planina Log Splitter is not operating, it could be due to several reasons. The conveyor belt may not be tensioned enough, so tension the conveyor belt. Check if there is enough oil in the hydraulic system, and add more if necessary. Also, the speed regulator might be fully screwed down; set it appropriately. Lastly, stuck wood might be preventing the conveyor belt from moving, so clean the conveyor belt area, ensuring you stop the machine during the cleaning procedure.
  • Q
    qwilliamsSep 9, 2025
    Why is the hydraulic cylinder leaking on my Tajfun Planina RCA 380?
    • J
      John PhillipsSep 9, 2025
      If the hydraulic cylinder on your Tajfun Planina Log Splitter is leaking, it's likely due to worn-out seals, which need to be replaced. Alternatively, the piston-rod might be damaged, requiring you to replace the cylinder.

Summary

1. General

Manufacturers Address

Manufacturer's contact and location details.

Application

Details the intended use and capabilities of the firewood processor.

Scope of Delivery

Lists the components included with the firewood processor.

Optional Equipment

Describes optional accessories available for the firewood processor.

Technical Data

Key technical specifications of the firewood processor.

2. Safety Instructions

3. Machine Setup and Operation

Discharge Conveyor Assembly

Steps for assembling the discharge conveyor.

Tractor PTO Shaft Drive

Instructions for connecting and using the PTO shaft.

Starting Up

Procedures for safely starting the firewood processor.

Transport Position of the Machine

How to position the machine for safe transport.

4. Operating the Firewood Processor

Noise

Information on noise levels during operation.

Log Feeding

Procedures for feeding logs into the processor.

Sawing

Detailed steps for the sawing operation.

Splitting

Explanation of the splitting process and controls.

Discharge Conveyor

Operation and adjustment of the discharge conveyor.

5. Maintenance and Repair

Cutting Chain Replacement

Step-by-step guide for replacing the cutting chain.

Cutting Chain Tensioning

How to properly tension the cutting chain.

Changing the Splitting Wedge

Procedure for replacing the splitting wedge.

Hydraulic System Oil Change

Instructions for changing hydraulic system oil.

Oil Filter Maintenance

Guide for cleaning and replacing the oil filter.

Lubrication of the Angle Multiplication Gear

Details on lubricating the angle multiplication gear.

Cutting Chain Lubrication

Information on lubricating the cutting chain.

Troubleshooting

Common problems and their solutions.

Maintenance Plan

Schedule for routine maintenance tasks.

Cutting Chain Belt Replacement

Procedure for replacing the cutting chain belt.

Indications of Improper Use

Signs of damage from incorrect operation.

Supplies

List of parts considered supplies.

Spare Parts Ordering

Information needed for ordering spare parts.

Warranty Sheet
