Talius Habitat Screen
TM
Installation Guide
Version 2018.1, 2
©TALIUS
CONTENTS
Preparation for Through Wall Operator Applications
Mounting Guide Rails and Panel Box
Limit Setting for Motorized Units
Habitat Screen Adjustment Guide – Final Adjustments to Ensure Smooth Operation
RECOMMENDED INSTALLATION TOOLS AND MATERIALS
Each Habitat Screen installation requires a minimum of 2 installers. Not all installations are the same. While the
following items will not be required on every installation, this is a list of minimum requirements that we
recommend for the majority of Habitat Screen installations. While we do not supply common tools and
hardware, contact us to purchase the specialized tools like motor tester cables.
Please note: Talius does not supply the fasteners for installation. We believe this is better handled
by the Talius Dealer, based on the on-site construction considerations.
Level 4’, tape measure, markers
Side cutters, wire strippers
Short and tall ladders, tool pouch
Cordless drill, indexed drill bit set
Masonry drill or ½" hammer drill
Spare lag bolts, masonry anchors
Full screwdriver set, multi-driver
set
Long ؽ" (13mm) and ؾ"
(19mm)
Needle-nose pliers, regular pliers
Drill bits, block of wood
035-.040"(0.9 - 1.0mm) feeler
gauge
Plastic caps for screw holes
Rivet gun, variety of spare rivets
Caulk gun, caulking and sealants
Touch-up paint and brushes:
brown,
white, silver, beige, and black
Extension cords, cleansers, rags
Ø8.5mm/Ø5mm step drill bit
Wood and concrete chisels,
hammer
Tubular motor limit combs /
adjusters
Ø10mm/Ø5mm step drill bit
Electrical tape, masking and duct
tape
Tubular motor tester cable
To Next Page
