Tamjets A4 Skyhawk - Page 19

37. Adjust the engine location to insure that the FRONT EDGE of the pipe
Bellmouth Inlet is EVEN with the REAR of the Engine Exhaust nozzle. Inserting
the engine nozzle too far into the tailpipe can result in high engine EGT’s.
38. Fuel cell and UAT installation Diagram
