PARTS INFORMATION
custsvc@nikko-tanaka-usa.com
Page 2
THT-2100
ENGINE / CYLINDER, PISTON, CRANKSHAFT • FIGURE 1
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
1-1 1570650091 CAP,SPARK PLUG ASS'Y 1
1-2 01804075200 PLUG,SPARK 1
1-3 0010650090 SET,CYLINDER 1 Includes cylinder gasket
1-4 99416050201 SCREW,5X20/WS 2
1-7 0170650020 GASKET, CYLINDER 1
1-8 04100601210 RING,PISTON 1
1-9 0300650090 SET,PISTON 1 Includes rings, and circlips
1-10 03706500200 PIN,PISTON 1
1-11 03901620200 CIRCLIP,PISTON PIN 2
1-12 04606500801 CRANKSHAFT 1
1-13 99962081225 BEARING,NEEDLE,F-810 1
1-21 0720650090 CRANKCASE ASS'Y 1 Crankcase assy includes bearings, seals
1-22 09006500200 GASKET,CRANKCASE 1 and gasket.
1-23 99966122206 SEAL,OIL,#TC12227 2
1-24 99961600100 BEARING,BALL,#6001 2
1-25 33000200210 SHIM,12.2X19X.10 V Shims are "as needed" to obtain
1-25 33000200220 SHIM,12.2X19X.15 V correct side clearance
1-25 33000200230 SHIM,12.2X19X.20 V
1-25 33000200240 SHIM,12.2X19X.30 V
1-26 59900601200 CUSHION 1
1-27 1672153280 COIL,IGNITION 1
1-28 99416040226 SCREW,WS,4X22 2
1-30 99414050301 SCREW,5X30/S 3
1-31 1552152380 ROTOR, MAGNETO 1
1-32 99201080011 WASHER,8 1
1-33 99210080012 WASHER,S,8 1
1-34 99101080011 NUT,8 1
1-35 10002100200 BOLT,STUD,6X22 2
1-36 25006500200 TUBE,INSULATOR 1
1-37 1780650080 CORD,STOP COMPLETE 1
