Page 1
THT-210S
CYLINDER, PISTON, CRANKSHAFT • FIGURE 1
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
1-1 1570650091 CAP,SPARK PLUG ASS'Y 1
1-2 0181166021 PLUG,SPARK 1
1-3 0010650A90 CYLINDER SET 1 Includes gasket
1-4 99461050184 BOLT,HEX,5X18,S 2
1-7 0170650020 GASKET,CYLINDER 1
1-8 04100601210 RING,PISTON 1
1-9 0300650A90 PISTON SET 1 Includes rings and circlips
1-10 03706500200 PIN,PISTON 1
1-11 03901620200 CIRCLIP,PISTON PIN 2
1-12 04606500801 CRANKSHAFT 1
1-13 99962081225 BEARING,NEEDLE,F-810 1
1-27 1672153380 COIL,IGNITION 1
1-28 99464040184 BOLT,HEXT 4X18WS 2
1-29 2740700D80 CORD,130mm 1
1-36 25006500200 TUBE,INSULATOR 1
1-37 1780650080 CORD,STOP 1
