Tanaka TPH-260PF - Cylinder, Piston, Crankshaft, and Ignition Components

www.tanakapowerequipment.com
PARTS INFORMATION
custsvc@nikko-tanaka-usa.com
Page 1
TPH-260PF
CYLINDER, PISTON, CRANKSHAFT, IGNITION • FIGURE 1
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
1-1 1570168090 CAP,SPARK PLUG ASS'Y 1
1-2 01802233200 PLUG,SPARK 1
1-6 0010760090 CYLINDER SET 1 Includes gasket
1-7 99461050184 BOLT,HEX,5X18,S 4
1-9 0170735020 GASKET,CYLINDER 1
1-11 04101601200 RING,PISTON 2
1-12 0300750090 PISTON SET 1 Includes rings and circlips
1-13 03901620200 CIRCLIP,PISTON PIN 2
1-14 0370704520 PIN,PISTON 1
1-16 0460735082 CRANKSHAFT 1
1-17 99962081225 BEARING,NEEDLE,F-810 1
1-45 1910168090 WIRE,LEAD ASS'Y 1
1-46 99464040184 BOLT,HEXT 4X18WS 2
1-47 1820186A201 WASHER,SPECIAL 2
1-50 1672101290 COIL,INGITION 1
