1 DESCRIPTION OF EQUIPMENT
1.1 Electrical Specification
1.1.1 Supply Requirements
KV5-100 mk2 115/230V ±10% 600VA max
KV3-250 mk2 115/230V ±10% 900VA max
KV4-300 mk2 230V ±10% 1400VA max
KV5-200 mk2 230V ±10% 1100VA max
KV6-80 115/230V ±10% 600VA max
1.1.2 Output Specifications
The output voltage, current and duty cycle are as follows:
Unit Output voltage
Output current
5 min on/
15 min off
1 min on/
15 min off
40 seconds on/
15 min off
KV5-100 mk2 0-5kV 100mA - -
KV3-250 mk2 0-3kV 125mA 250mA 300mA
KV4-300 mk2 0-4kV 200mA 300mA -
KV5-200 mk2 0-5kV 100mA 200mA -
KV6-80 0-6kV 80mA - -
One side of the high voltage transformer output is connected to the earth system of the
equipment.
1.1.3 Zero Voltage Interlock
The equipment is fitted with a zero volt interlock system on the output control. This interlock
prevents the output being energised unless the output control is in the minimum output
position.
1.1.4 External Interlock
The equipment is fitted with a external interlock system. The interlock socket on the back
panel must have a short circuit across it terminals to enable the output to be energised.
Note: the open circuit voltage across the interlock terminals is 240Vac and is connected
directly to the mains supply.
