Tangent DAB-50 - Connection; Audio Connection Layout

12
CONNECTION
Audio connection layout
Subwoofer
(Optional)
PHONO
TUNER DVD CD AUX 1 AUX 2 FUNCTION
VOLUME
POWER
HEADPHONE
AMP-50 AMPLIFIER
Analog amplifier/receiver
PHONO
TUNER DVD CD AUX 1 AUX 2 FUNCTION
VOLUME
POWER
HEADPHONE
AMP-50 AMPLIFIER
Digital amplifier/receiver
Item No.: 11048.01
Power Rating 230-240 V AC~50Hz
Model: DAB-50
Max Power Consumption: 30W
Serial No.:
Stereo Output
Optical Output
Antenna
Contrast
This page only contains suggestions for connection of your Eltax DAB-50. Note that the
accessories in the pictures on this page are not included in the supply.
