SPEAKER WIRING DIAGRAM
Connect the RED[+] and Black [-] terminals from the active speaker to the
corresponding terminals on the passive speaker using the included speaker
cable. The active speaker has to be placed on the left of your setup, the pas-
sive speaker on the right. Sheath on cable must be stripped on all ends.
Note : Please do not connect two active speakers in stereo.
Connect the power cable.
