SECONDARY SPRAY APPLICATOR MAINTENANCE
www.tanningessentials.co
TROUBLESHOOTING - BLOCKED NOZZLE OR CONTINUOUS SPRAY
WITHOUT PRESSING THE TRIGGER
STEP 1 Locate and unscrew retaining ring. To release; turn retaining ring in an
anti-clockwise motion.
STEP 2 Gently pull on the adjustable nozzle to remove.
STEP 3 Gently remove the metal disc and spring.
STEP 4 Fit an 8mm spanner to the flat edges of the fluid nozzle and turn
anti-clockwise to unscrew.
STEP 5 Ensure you do not misplace the o-ring seal, which is located behind the
fluid nozzle .
STEP 6 Once removed, visually inspect the fluid nozzle for small particles or
blockages - rinse thoroughly with hot water.
STEP 7 Gently wipe the fluid needle to clean and remove any debris (the fluid
needle should not be removed from the applicator at any time).
STEP 8 Once visually clear of any debris, re-attach fluid nozzle, ensuring the
O-ring is in position, then use the spanner (8mm) to gently tighten back
into place.
STEP 9 Replace spring, then gently insert metal disc ensuring the grooves on
the disc line up with the sides and the raised front is forward facing.
STEP 10 Replace adjustable nozzle and rotate back into position.
STEP 11 Repeat previous step, this time with the retaining ring.
