CMS501
Tannoy adopts a policy of continuous improvement and product specification is subject to change
CMS501 data file // issue 1.06 // 10.01.08
DIMENSIONAL SKETCHES
TEMPLATE HOLE CUTOUT
SIZE -
190mm (7.50")
CMS501 BM
TEMPLATE HOLE CUTOUT
SIZE -
190mm (7.50")
CMS501 PI
207.00
[8.10"]
189.50
[7.50"]
5.00
[0.20"]
210.00
[8.20"]
181.30
[7.14"]
210.00
[8.20"]
136.00
[5.40"]
5.00
[0.20"]
181.30
[7.14"]
8001 4450 CMS501 BM White / paintable 2
8001 4460 CMS501 PI White / paintable 2
8001 4180 CMS501 Plaster (Mud) Ring Zinc plated steel 10
8001 3830 CMS501 PI back can Zinc plated steel 1
PART NUMBER PACKED QUANTITYBAFFLE / GRILLE COLOURMODEL NAME
Ordering Information
