CMS501
Tannoy adopts a policy of continuous improvement and product specification is subject to change
CMS501 data file // issue 1.06 // 10.01.08
DIMENSIONAL SKETCHES
1
88.00
[
7.40"]
288.00
[11.34"]
80.00
[3.15"]
151.50 [5.96"] 151.50 [5.96"]
27.00
[1.06"]
1
5.00
[
0.59"]
16.00 [0.63"]
4.50 [0.18"]
522.00 [20.55"]
81.00
[3.19"]
360.00 [14.17"]
15.00 [0.59"]
635.00 [25.00"]
15.00 [0.59"]
25 POSITIONS
SUPPLIED ACCESSORIES
C-RING
TILE BRIDGE
OPTIONAL ACCESSORIES
PLASTER (MUD) RING
60.00
[2.36"]
180.00 [7.09"]
205.00 [8.07"]
230.00 [9.06"]
255.00 [10.04"]
280.00 [11.02"]
305.00 [12.01"]
650.00 [25.59"]
10.00
[0.39"]
188.00 [7.40"]
254.00 [10.00"]
The PI back can accepts direct
connection to installed conduit in two
ways using squeeze connectors:
Any of the three knock-out points at the
side 19mm / 22mm / 28mm
(0.75
" / 0.87" / 1.10")
1
2
2
88.00
[11.34"]
256.00
[10.08"]
8.80
[0.35"]
136.20
[5.36"]
153.5
[6.04"]
186.40
[7.34"]
22mm (0.87") via the clamp location at
the rear after first removing cable clamp
TEMPLATE HOLE CUTOUT
SIZE - 190mm (7.50")
CMS501 PI BACK CAN
