Di5a
Tannoy United Kingdom
Tannoy North America
Tannoy Deutschland
Tannoy France
T: 00 44 (0) 1236 420199
T: 00 1 (519) 745 1158
T: 00 49 (180) 1111 881
T: 00 33 (0)1 7036 7473
E: enquiries@tannoy.com
E: inquiries@tannoyna.com
E: anfragen@tannoy.com
E: ventes@tannoy.com
Tannoy adopts a policy of continuous improvement and product specification is subject to change
T
he full bandwidth, active surface mount speaker system shall consist of a 110mm (4.50") full range, point source ICT™ transducer mounted in an optimally
t
uned vented, injection moulded high impact polystyrene (HIPS) enclosure. The protective grille shall be constructed from steel with a weather resistant coating.
Performance of the Di5a surface mount speaker shall meet or exceed the following criteria: The system shall have a conical coverage pattern of 90 degrees
(-6dB). Frequency response measured on axis shall be 90Hz - 30kHz (-10dB from rated sensitivity, average over stated bandwidth. Measured at 1 metre in an
anechoic chamber) with no equalisation. Rated power output shall be 30W RMS and rated maximum SPL shall be 109dB (peak). (Unweighted pink noise input,
measured at 1 metre in an anechoic chamber).Input sensitivity shall be 775mV (balanced) and 500mV (unbalanced). Input impedance shall be 11kOhm
(balanced) and 7kOhm (unbalanced). Thermal protection and soft limiting shall be provided.
A 6-way Euro-type input / output connector, unbalanced RCA (phono) input and IEC type C13 main input shall all be provided. 2 x M8 yoke bracket inserts are
provided for use with the supplied yoke bracket.
T
he dimensions shall not exceed 240.70 x 155.00 x 162.00mm (9.47 x 6.10 x 6.38”).
The surface mount speaker system shall be the.....Di5a.
Architectural specifications
