Specifications
TD10
PERFORMANCE
Recommended amplifier power 50 - 200 Watts RMS
Continuous power handling 130 Watts RMS
Sensitivity (2.83Volts @ 1 metre) 91dB
Nominal impedance 6 Ohms
Frequency response 38Hz - 54kHz -6dB usable output to 100kHz
DRIVE UNITS
Dual Concentric™ high frequency 25mm (1.00") 50-micron aluminium dome with Tulip
WaveGuide™
Dual Concentric™ low frequency 250mm (10.00") paper pulp cone with a twin roll
impregnated fabric surround
SuperTweeter™ 25mm (1.00") 25 micron titanium dome, with neodymium
magnet system
Dispersion 90° conical
CROSSOVER
Frequency Dual Concentric™ 1.2 kHz
SuperTweeter™ 14 kHz
Type Dual Concentric™ Bi-wired, hard-wired passive, low loss, 3rd order low pass,
1st order high pass
SuperTweeter™ 3rd order high pass filter
CONSTRUCTION
Enclosure type Twin port reflex
Volume 67 Litres
Dimensions 1015 x 350 x 370mm (40.00 x 13.80 x 14.60")
Additional features High-density 25mm (1.00") birch ply enclosure, internally
cross braced
Weight 32 kgs (70.5 lbs)
Finish American cherry with polished alloy trim detail
Front baffle panel High-density 38mm (1.50") birch ply
