5. Installation Guidelines

DVS (EN54) Operation Manual rev 1.1.1

5. Installation Guidelines

1. Fixtheyokebrackettothesurfaceusingasuitablexingmethod.(Fig.1)



2.Feedthespeakercablethroughthecableclampcoverthenconnectthe

Euro-typeplugtothewires,observingthecorrectpolarity.(Fig.2)



3.Forconnectiontotheloudspeaker,usePins1(+)and2(-).

Pins3(-)and4(+)areinparallelforconnectiontoadditionalspeakers

inadistributedline.(Fig.3)



4.Offerthespeakeruptothebracketandattachusingthescrew

capsthentightenusingthebracketclamptoolprovided.(Fig.4)



5.ConnecttheEuro-typeplugthenreplacethecableclampcoverto

ensurethespeakerissealed.(Fig.5)



6.TheDVS4(EN54)modelsarettedwith30Wtransformers.(Fig.6)

THESPEAKERISSUPPLIEDINLOWIMPEDANCEMODE.

NEVERCONNECTTHESPEAKERTOA70/100VOLTAMPLIFIERWHILE

ITISSETFORLOWIMPEDANCE.



7.TheDVS6(EN54)modelsarettedwith60Wtransformers.(Fig.7)

THESPEAKERISSUPPLIEDINLOWIMPEDANCEMODE.

NEVERCONNECTTHESPEAKERTOA70/100VOLTAMPLIFIERWHILE

ITISSETFORLOWIMPEDANCE.

Fig.1

Fig.2

Fig.3

Fig.4

Fig.5

Fig.6

Fig.7
