4. Standard Accessories
6
DVS (EN54) Operation Manual rev 1.1.1
5. Installation Guidelines
1. Fixtheyokebrackettothesurfaceusingasuitablexingmethod.(Fig.1)
2.Feedthespeakercablethroughthecableclampcoverthenconnectthe
Euro-typeplugtothewires,observingthecorrectpolarity.(Fig.2)
3.Forconnectiontotheloudspeaker,usePins1(+)and2(-).
Pins3(-)and4(+)areinparallelforconnectiontoadditionalspeakers
inadistributedline.(Fig.3)
4.Offerthespeakeruptothebracketandattachusingthescrew
capsthentightenusingthebracketclamptoolprovided.(Fig.4)
5.ConnecttheEuro-typeplugthenreplacethecableclampcoverto
ensurethespeakerissealed.(Fig.5)
6.TheDVS4(EN54)modelsarettedwith30Wtransformers.(Fig.6)
THESPEAKERISSUPPLIEDINLOWIMPEDANCEMODE.
NEVERCONNECTTHESPEAKERTOA70/100VOLTAMPLIFIERWHILE
ITISSETFORLOWIMPEDANCE.
7.TheDVS6(EN54)modelsarettedwith60Wtransformers.(Fig.7)
THESPEAKERISSUPPLIEDINLOWIMPEDANCEMODE.
NEVERCONNECTTHESPEAKERTOA70/100VOLTAMPLIFIERWHILE
ITISSETFORLOWIMPEDANCE.
4. Standard Accessories
CableClampCover
YokeBracket
(Suppliedwith
xings)
BracketClampTool
