ECLIPSE MANUAL_07
TECHNICAL SPECIFICATIONS
ECLIPSE MINI ECLIPSE CENTRE
PERFORMANCE
Recommended amplifier power
(Watts RMS)
15 - 60 15 - 90
Continuous power handling
(Watts RMS)
30 45
Peak power handling (Watts) 140 180
Sensitivity (2.83 Volts @ 1 m) 86 dB 90 dB
Nominal impedance (Ohms) 8 8
Frequency response (-6 dB) 58 Hz – 32 kHz 67 Hz – 32 kHz
DRIVE UNITS
High frequency 28 mm (1.1”) Nitro-urethane
damped layer woven polyester
dome, neodymium magnet system
28 mm (1.1”) Nitro-urethane
damped layer woven polyester
dome, neodymium magnet system
Low frequency 100 mm (4”) Multi-fibre coated
pulp paper cone
2 x 100 mm (4”) Multi-fibre
coated pulp paper cone
CROSSOVER
Crossover frequency 2.2 kHz 2.4 kHz
Crossover type Passive low loss 2nd order
low pass, 3rd order high pass
Passive low loss 2nd order low
pass, 3rd order high pass
CONSTRUCTION
Enclosure type Rear ported reflex Rear ported reflex
Volume 3.0
litres (0.11 cu. ft.) 5.6 litres (0.2 cu. ft.)
Dimensions (H x W x D)
(incl. plinth* & grille)
225.0 x 145.0 x 175.0 mm
(8.9 x 5.7 x 6.9”)
157.0 x 400.0 x 160.0 mm
(6.2 x 15.8 x 6.3”)
Net weight 2.9 kg (6.4 lbs) 3.6 kg (7.9 lbs)
Finish Black Oak Black Oak
