06_ ECLIPSE MANUAL
TECHNICAL SPECIFICATIONS
ECLIPSE ONE ECLIPSE TWO ECLIPSE THREE
PERFORMANCE
Recommended amplifier power
(Watts RMS)
15 - 70 15 - 90 15 - 120
Continuous power handling
(Watts RMS)
35 45 60
Peak power handling (Watts) 140 200 240
Sensitivity (2.83 Volts @ 1 m) 87 dB 88 dB 90 dB
Nominal impedance (Ohms) 8 8 8
Frequency response (-6 dB) 55 Hz – 32 kHz 44 Hz – 32 kHz 38 Hz – 32 kHz
DRIVE UNITS
High frequency 28 mm (1.1”) Nitro-urethane
damped layer woven
polyester dome, neodymium
magnet system
28 mm (1.1”) Nitro-urethane
damped layer woven
polyester dome, neodymium
magnet system
28 mm (1.1”) Nitro-urethane
damped layer woven
polyester dome, neodymium
magnet system
Low frequency 127 mm (5”) Multi-fibre coated
pulp paper cone
127 mm (5”) Multi-fibre coated
pulp paper cone
127 mm (5”) Multi-fibre coated
pulp paper cone x 2
CROSSOVER
Crossover frequency 3.2 kHz 3.2 kHz 3.2 kHz
Crossover type Passive low loss 2
nd
order
low pass, 3
rd
order high pass
Passive low loss 2
nd
order
low pass, 3
rd
order high pass
Passive low loss 2
nd
order low
pass, 3
rd
order high pass, bi- wired
CONSTRUCTION
Enclosure type Rear ported reflex Rear ported reflex Rear ported reflex
Volume 8.0 litres (0.28 cu. ft.) 18.9 litres (0.67 cu. ft.) 26.8 litres (0.95 cu. ft.)
Dimensions (H x W x D)
(incl. plinth* & grille)
300 x 170 x 255 mm
(11.8 x 6.7 x 10”)
909 x 269.6 x 287 mm
(35.8 x 10.6 x 10.9”)*
959 x 269.6 x 287 mm
(37.8 x 10.6 x 10.9”)*
Net weight 4.5 kg (9.9 lbs) 11.5 kg (25.4 lbs) 12.1 kg (26.7 lbs)
Finish Black Oak Black Oak Black Oak
