10. Technical Specifications
Frequency response (1) +/- 3dB 85Hz - 22kHz
Recommended Amplifier Power 150 - 260 watt / 8 ohm
Power Handling Average(2) Programme Peak (10ms)
130 watt 260 watt 520 watt
Sensitivity (1)
2.83 volt @ 1m 92 dB 95 dB (half space)
Maximum SPL (3) Average Peak Average (half space) Peak (half space)
@ 1m 113 dB 119 dB 116dB 122dB
Impedance Nominal 8.0 ohm
Minimum 6.4 ohm
DI Averaged (PCQ) 8.2, 250 Hz - 16 kHz
@ 1kHz (ISO) 6.3
@ 2kHz (ISO) 7.2
@ 4kHz (ISO) 10.5
@ 8kHz (ISO) 12.3
@ 16kHz (ISO) 13.7
Q Averaged (PCQ) 9.44, 250 Hz - 16 kHz
@ 1kHz (ISO) 4.3
@ 2kHz (ISO) 5.2
@ 4kHz (ISO) 11.2
@ 8kHz (ISO) 17.0
@ 16kHz (ISO) 23.4
Distortion
0.1 Full Power 2nd Harmonic 3rd Harmonic
250 Hz 1.00% 0.31%
1000 Hz 0.25% 0.56%
10000 Hz 1.4% 0.14%
0.01 Full Power 2nd Harmonic 3rd Harmonic
250 Hz 0.31% 0.25%
1000 Hz 0.4% 0.03%
10000 Hz 0.18% 0.5%
Driver Complement 1 x 8” (200mm) Constant Directivity Dual Concentric
Type number 2062
Crossover Point Passive 1.7 kHz
4
th
order high pass, 2
nd
order low pass
Dynamic HF protection
Enclosure 16.6 litre vented, 15mm MDF
Finish Textured black\grey paint
Protective Grille Perforated steel, black with 58% free air flow
Connectors 2 x 4mm binding posts
Fittings 1 x Blank plate for pole mount socket
4 x M8 inserts for CUB8 Bracket
Dimensions 388mm(H) x 280mm(W) x 280mm(D)
15.28ins(H) x 11.02ins(W) x 11.02ins(D)
Weight 8.2 Kg (18.04 lbs)
NOTES: (1) Average over stated bandwidth. Measured at 1m on axis, in an anechoic chamber.
(2) Long term power handling capacity as defined in EIA standard RS - 426A.
(3) Unweighted pink noise input, measured at 1m
Tannoy operate a policy of continuous research and development. The introduction of new materials or manufacturing methods will always equal
or exceed the published specifications which Tannoy reserve the right to alter without prior notice.
Please verify the latest specifications when dealing with critical applications.
