9
Fig 2: Terminal Panel
Fig 3: Single Wire Mode
LOW FREQUENCY
NEGATIVE(-) TERMINAL
HIGH FREQUENCY
NEGATIVE(-) TERMINAL
LOW FREQUENCY
POSITIVE(+) TERMINAL
HIGH FREQUENCY
POSITIVE(+) TERMINAL
POWER AMPLIFIER
SPEAKER
-+-
LR
+
TO RIGHT
LINKS IN PLACE
