The device is an Air Fryer Oven, model number NB-AF002, designed for household use. It combines multiple cooking functions within a single appliance, offering versatility for various culinary needs.

Function Description

The Air Fryer Oven features a multi-function knob that allows selection of different cooking modes:

Air Fryer Function: This is the primary function, ideal for cooking foods like french fries and chicken wings, utilizing intense heat and maximized airflow for crispy results.
Toast Function: Provides upper and lower heating for toasting bread and similar items.
Toast + Convection Function: Combines upper and lower heating with convection for more even and thorough toasting.
Dehydrate Function: Designed for drying fruit or vegetable chips, using low and stable heat with steady airflow.
Broil Function: Utilizes upper heating for broiling.
Bake Function: Employs lower heating for baking.

In addition to the function selector, the oven has a Temperature Knob that allows users to select a desired temperature ranging from 180°F to 450°F, accommodating various practical cooking situations. A Time Knob controls the cooking duration, with settings up to 60 minutes. The timer counts down automatically and includes a bell ring to signal completion. For safety, the time knob must be set to "OFF" when the cooker is not in use. If cooking finishes before the set time, the timer should be manually turned back to "OFF" to power off the oven.

The oven body includes a control panel, a glass door for monitoring food during cooking, and a door handle. It stands on oven feet.

Important Technical Specifications

Voltage: 120V ~ 60Hz
Power: 1200W
Capacity: 17 Quart

Usage Features

Before First Use:

Place the Air Fryer Oven on a flat, level, heat-resistant surface.
Ensure at least four inches (ten centimeters) of space on all sides of the oven for adequate air circulation.
Check that the Crumb Tray is in place and that the oven is empty.
Plug the power cord into a properly installed wall outlet. The appliance has a polarized plug (one blade wider than the other) for safety; if it doesn't fit, reverse the plug. Do not attempt to alter this safety feature.
Preheat the oven for 10 minutes by setting the temperature, time, and heating stage.
Insert the baking tray or basket with food.
Use either the tray or basket one at a time for optimal cooking.
Monitor food through the glass door. For thick food, it is recommended to turn it over once or twice using oven mitts.
Once cooking is finished, the timer will automatically shut off with a bell ring. If cooking finishes early, turn the timer to OFF.
Carefully remove the food.

General Operation Notes:

Objects should not be stored on top of the oven. Remove all objects before turning on the oven.
The exterior walls get very hot during use; keep out of reach of children.
Always use oven mitts when opening and closing the lid to avoid accidental burns, scalding, or steam release.
The appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless supervised or instructed.
Close supervision is necessary when used by or near children. Children should not play with the appliance.
Use the appliance only for intended household purposes as described in the User Manual.
Do not place the appliance against a wall or other appliances, on a stove, near gas/electric burners, or in a heated oven.
Do not leave the appliance unattended while in use.
Keep the air fryer away from flammable materials (curtains, tablecloths, etc.).
After using, the metal cover inside is very hot; avoid contact. Unplug from the outlet when not in use and before cleaning. Allow to cool before handling parts or cleaning.
If dark smoke comes out, immediately unplug the appliance. Wait for the smoke to stop before removing the pan.

Troubleshooting:

Air fryer oven does not work: Check if the power cord is securely plugged, the oven door is closed, and test the circuit with another appliance.
Remaining odor: A plastic smell during initial uses is normal, non-toxic, and dissipates quickly. Run the oven for a few minutes before first use.
Dark smoke comes out: Immediately stop cooking, unplug, and allow to cool. Clean all accessories and the cooking chamber thoroughly.
White smoke comes out: Caused by oil leaking into the crumb tray from greasy foods. Avoid air frying high-fat foods. Ensure the drip pan and inside are cleaned properly after each use.
Heating elements are not heating up: Ensure the function selector is positioned to the desired cooking setting.
Overcooked/undercooked foods: Adjust the timer setting and rack placement as needed.
Burnt smell: Indicates food build-up inside the appliance, on heating elements, or in the drip/baking pan. Refer to the "Cleaning and Maintenance" section.

Maintenance Features

Cleaning and Maintenance:

Proper maintenance ensures years of service. Clean the product after every use. This product contains no user-serviceable parts and requires little maintenance.
WARNING: Unplug the product and allow it to cool before cleaning.
Clean the interior and exterior surfaces of the appliance with a damp cloth or sponge. Wipe dry with a soft cloth. Do not use abrasive or metallic materials.
Do not immerse the appliance in water.
Do not use abrasive cleaners or sharp tools to clean the appliance.
Clean the interior chamber with a clean damp cloth.

Regular Check:

Have your air fryer oven checked regularly for any sign of malfunction.
Check if the plug, cord, or appliance is damaged. Stop using, check the FAQ, and contact the Paris Rhône Support Team at appliancehelp@tyutech.com.

The manufacturer is Shenzhen Aspiron Technology Company Limited, located at Room 2803B, Building C, Galaxy World Phase II, Minle Community, Minzhi Street, Longhua District, Shenzhen, Guangdong, China.
