19
Sub-Compact Rotary Tiller DLT & DLT-S Series
Item
Part # Description Qty.
BM101530 Bolt- M10 x 1.5 x 30
NM1015 Nut- M10 x 1.5
DP1003 A Frame
LW10 Lock Washer- M10
DP1005 Lower Suspension Pin
DP1006 Small Bevel Gear
B32010 Bearing- 32010
DP1008 Gasket- Dia. 80
DP1009 Cap- Dia. 80
10 ABM101525 Bolt- M10 x 1.5 x 25
11 LW10 Lock Washer- M10
12 BM061016 Bolt- M6 x 1.0 x 16
13 DP1013 Cap
14 LW06 Lock Washer- M6
15 DP1015 Gasket
16 DP1016 Intermediate Gearbox
17 SRE-35 Snap Ring- External- M35
18 DP1018 Big Bevel Gear
19 B30207 Bearing- 30207
20 OS355512 Oil Seal- M35 x 55 x 12
21 DP1021 Gasket- Dia. 90
22 BM101525 Bolt- M10 x 1.5 x 25
23 DP1023 Main Frame Pipe- DLT042
23 DP10231 Main Frame Pipe- DLT050
24 ABM101530 Allen Head Bolt– M10 x 1.5 x 30
25 FW10 Flat Washer- M10
26 LW10 Lock Washer- M10
27 LNM10 Self-locking Nut- M10 x 1.5
28 DP1028 Tailgate Chain
29 DP1029 Hook
30 DP1030 Tail Gate- DLT042
30 DP10301 Tail Gate- DLT050
31 DP1031 Output Shaft- DLT042
31 DP10311 Output Shaft- DLT050
32 B32010 Bearing- 32010
33 DP1033 Rod- DLT042
33 DP10331 Rod– DLT050
34 DP1034 Small Sprocket Wheel
35 SW24 Stop Washer
DLT Series Rotary Tiller
