WAL 14 A1
English - 5
4. Technical specifications
The rating plate for the outdoor camera can be found on the mounting plate (10).
LED emitter
Model name: WAL 14 A1
Operating voltage: 220 – 240 V
~
, 50 Hz
Total power consumption: approx. 20 Watt
Power consumption of light without
auxiliaries:
approx. 18 Watt
Lights: 28 LEDs at 0.5 W each
Luminous flux: approx. 1250 lumen
Colour temperature: Approx. 5,000K
Energy efficiency class of LED emitter: A+
Adjustable light time:
For movement sensor:
Manual setting:
Approx. 10 sec. (+/- 5 sec.) to approx. 20 min. (+/- 5 min.)
3 hours, 6 hours or continuous when dark (adjustable using
twilight sensor)
Max. area projected: Approx. 50 m² if mounted at height of approx. 2.50 m
Operating position: Vertical – LED-emitter on top, movement sensor underneath
Ambient temperature: -33°C - + 40°C
Safety class: I (with ground wire connection)
Degree of protection: IP54
Dimensions (W x D x H): approx. 179 x 165 x 256 mm
Weight: approx. 920 g
Camera:
Resolution: 1280*720 pixels
Frame rate: 1-20 images per second (adjustable)
Viewing angle: Approx. 94° horizontal, approx. 48° vertical
Micro SD card (not included): Class 10, max. 128 GB
Movement sensor:
Sensor detection angle: Max. 180°
Sensor range: Max. 10 m
Light sensitivity: Adjustable using the app
Swivel range (mechanical): Approx. 120° horizontal
WiFi / Control app L-Guard HD
WiFi standard: 802.11 b / g / n
WiFi frequency band: 2.4GHz
Wi-Fi transmission power: approx. 8.7 mW
App compatibility: iOS 8.0 (and higher) / Android 4.4 (and higher)
The technical data and design may be changed without prior notice.
