Target 5948307T - Cabinet Frame Assembly

1
step
Proper orientation of CAM LOCK
(2) x2
cam bolt
(1)
x2
cam lock
(8)
x3
#6x
7
16" screw
(12)
x1
left cabinet slide
A
1
1
2
2
8
8
8
3
(3) x1
wood dowel
7
12a
12a
marked with an "L"
1. Screw-in cam bolts must be screwed down flush.
2. Refer to page 6 for instructions on how to use the cam lock system.
