Info/ Tootja/ Ražotājs/ Gamintojas/ Изготовитель:
Tarmo Finland, PO Box 499, FI-33101 Tampere, Finland / Тампере, Финляндия
EN
MOISTURE METER
Please read this user manual thoroughly before using this meter and keep it handy for future reference.
Application
This meter is designed for testing moisture levels in dierent building materials. The accuracy of measu-
rement is increased by combining microcontroller technology with integrated characteristics for four ma-
terial groups.
Safety
Read the following safety information carefully before operating or servicing the meter.
Use the meter only as specified in this manual.
Do not allow the instrument or the measurement pins to touch any corrosive liquid.
The moisture meter must not be used in environments where explosive gases or vapours are present.
The measurement pins (electrodes) are extremely sharp. Be carefully when handling this instrument. Cover
the pins with the protective cap when the instrument is not in use.
Never use the meter if you suspect any type of electrical problem or short-circuiting in the area to be
measured. Electric shocks can damage the moisture meter and be hazardous for both person and property.
Do not expose the moisture meter to direct sunlight for any extended period. Using the meter in the presen-
ce of strong magnetic fields can lead to false readings.
Specifications
Electrode length 10 mm
Moisture range Wood: relative humidity (RH) 5–70 %
Building materials: relative humidity (RH) 5–70 %
Temperature range -20 – +70 °C / -4 – +158 °F
Moisture accuracy Wood: 5–30 %: ± 1 %
30–60 %: ± 2 %
60–70 %: ± 4 %
Other materials: ± 0.5 %
Temp. accuracy -20 – +70 °C / -4 – +158 °F: ± 1.5 °C / 2.7 °F
Auto power o Meter shuts o automatically after 120 seconds of
inactivity.
Power supply 9 V battery (1 x)
Operating temperature 0–50 °C / 32–122 °F
Operating humidity Relative humidity (RH) 0–85 %
Note
This moisture meter has a temperature compensation function. Allow a waiting time of 30 minutes if the
meter is moved between two very dierent temperatures. This will allow the meter to adjust to the environ-
ment and provide more accurate readings.
Meter Description
1. Protective cap
2. Measurement pins (electrodes)
3. LCD display
4. Power on/o key
5. Backlight key
6. °C/°F conversion key
7. MODE key
8. MAX/MIN key
LCD Display
1. Graphical display of moisture level
2. Auto power o icon
3. Numerical reading of ambient temperature
4. °C/°F icon
5. Low battery icon
6. SCAN and HOLD icon
7. MAX and MIN icon
8. Moisture unit
9. Numerical reading of moisture level
10. Material mode icon
Operating Instructions
Open the battery cover and insert a 9 V battery into the battery compartment.
Power on the meter, and then select the suitable measurement mode (MODE key) according to the object to
be measured. Please refer to the more specific materials list at the end of this manual.
Remove the protective cap to expose the measurement pins. Carefully push the measurement pins as far
as possible into the material under test. Take several readings in several locations on the material for the
best representation of the amount of moisture present. The measured values will be displayed on the LCD.
When the low battery icon “
” appears on the LCD, replace the battery in the meter.
Button Functions
Power on/o key
1.
2.
3.
4.
5.
6.
7.
8.
Press this key to power on or power o the meter.
Temperature unit conversion key
When the meter is on, press this key to switch the temperature units between °C and °F.
Backlight on/o key
In measurement mode, press this key quickly to switch between SCAN and HOLD mode. Long press this
key to turn on/o the backlight.
MODE key
When the meter is on, press the MODE key to select the suitable measurement mode according to the ob-
ject to be measured.
M1: Hard woods
M2: Medium-hard woods/materials
M3: Soft materials
M4: Concrete
Please refer to the more specific materials list at the end of this manual.
MAX/MIN key
In measurement mode, pressing this key will enter MAX or MIN mode. Press this key for a short time: the
MAX icon will appear on the LCD, which indicates the current maximum reading; press this key again to en-
ter MIN mode, which indicates the current minimum reading. Press this key once again to go back to the
normal SCAN measurement mode.
Notes
This meter has already been calibrated before delivery. Please do not revise the calibration parameters wi-
thout professional equipment and qualified personnel.
Maintenance, storage and disposal
Wipe the body with a dry cloth. Do not use abrasives or solvents on this instrument.
Do not store the meter near water or dusty areas, areas of high salinity, sulfur or other chemical substan-
ces or in high temperatures or high humidity. Remove the battery if the meter will not be used for long time.
If the battery leaks, it will damage the meter. The meter should be stored inside its protective case whene-
ver it is not being used.
The meter should not be disposed of with the general household waste. Dispose of the meter according to
your local recycling system.
Materials list
WOOD
Mode 1
Abachi Abura African mahogany
Agba Andiroba American Ash
Alder Aspen Alder (red, black)
Aiele Ash Japanese Ash
Beech Cardboard Basralocus
Birch Black Afara Beech (European)
Balsa Cedar Cupressus lusitanica
Campeachy Common beech Chestnut (sweet, red)
Dabema Douka Douglas fir
Ebiara Ebony Emien (Alstonia congensis)
Elm Guanandi Hickory/silver poplar
Hornbeam Hickory poplar Hornbeam white
Iroko Izombé Jarrah
Juniper Kapok Karri
Ipé Limba Logwood
Maple Mockernut hickory Niangon
Niove (Staudtia stipitata) Okoume Oak (holm oak)
Oak Parana pine Patagonian cypress
Pear wood Purple heart Rio rosewood
Red Oak Rosewood Red birch
Longleaf pine Small-leaved lime Small-leaved lime (American)
Willow Teak White hornbeam
Yellow birch White Oak Walnut tree
Mode 2
Cherry wood Common aspen Cherry mahogany
Cypress (red) Carpet Durmast oak
Damson wood Elm English Oak
Fibre board Kosipo Kaurane particleboard
Larch Limba Mahogany
Maritime pine Paper Pine
Plumwood Poplar Red sandalwood
Swiss pine Textiles Walnut
Gmelina Wood fibre board Western red cedar
White poplar White birch White maple
Mode 3
Afrormosia Cork Drywall
Imbuia Kokrodua Melamine particle board
Niove Bidinkala Rubber tree Sheetrock
Tola (real, red) Phenolic resin particle board
Mode 4
Concrete
