Part # Description Qty
Part #
Description Qty
4
Chassis Assy.
1
33
Hexagonal Socket Head Cap
Screw M8x50
1
5 Spring Washer Ø8 4 34 9J Joined Narrow V-Belt 1
6 Lock Nut Nylon M8 1 35 Outer Belt Guard 1
13 Engine 1 36
Flat Key 6
x50
1
14
Lock Nut Nylon M10
7
37
Hexagon Socket Set Screw
M10
x16
2
15 Spring Washer Ø10 9 38 Pulley Locker 1
16 Flat Washer Ø10 12 39 Bolt 2
17 Axle 1 59 Spring Washer Ø5 1
18 Handle Cover 2 78 Spring Washer Ø6 3
19 Lock Nut Nylon M12 4 91 Large Washer Ø8 2
20 Spring Washer Ø12 4 94 Flat Washer Ø6 1
21 Flat Washer Ø12 8 118 Inner Belt Guard 1
22 Hex Nut M10 2 119 Start Switch Assy. 1
23
Hex Bolt M10
x80
1 124
Hex Bolt M6
x12
1
24 Blade And Shaft Assy. 1 126 Centrifugal Clutch Bushing 1
25 Belt Pulley 1 131 Flat Washer Ø5 1
26
Hex Bolt M12
x40
4 132 Screw M5x10 1
27
Hex Bolt M8
x20
3 133
Hex Bolt M5
x30
1
28
Hex Bolt M10
x25
3 134 Cover Plate 1
29
Step Bolt M10
x45
4 135 Press Plate 1
31 Centrifugal Clutch 1 136 Hex Bolt M10x50 1
32 Axle Sleeve 1
To Next Page
