24
Replace fuses
Replace main fuse:
t Pull out the key and operate the parking brake (see Parking brake‘ Page 9).
t Fold the driver seat forward and open the battery cover.
t Disconnect battery plug with external battery charger.
Caution:
Use fuses with the correct value only!
False fuses can cause damages on the machine.
t Loose insulating nut (19mm spanner) of battery pole.
t Remove red insulating nut and replace the battery
charger leads.
t Replace main fuse.
Fuse ratings: co 2500/3500
Main fuse= 125A (Pudenz)
t Mount battery charger leads onto the battery pole and
mount the insulating nut of battery pole.
t Return tank in position for charging.
t Close the tank lid and fold the driver's seat back.
