Missteps can lead to personal injury and damage to the
machine.
Before inserting, please check:
• that the brush does not fall below the red marking (bristles)
or 1cm of bristle length.
• the pad for wear and cleanliness before use.
Failure to observe these instructions may result in inad-
equate cleaning results or even floor damage.
Any pad drive holder that is not intact or defective may
spin off the machine while working. In the case of non-
adherence there is a risk of accidents.
- Diversey recommends using cold water, as hot water
will adjust to the ground temperature as soon as it
comes into contact with the ground. Thus there are no
advantages to using hot water.
Using unsuitable products (e.g. products containing
chlorine, acids or solvents) may cause harm to health
and severe damage to the machine.
• Movement is only possible when the release button is
pressed. (See page 64)
• Position the tools under the brush unit.
• Press the Brush drive ON/OFF but-
ton.
The brush unit will be lowered auto-
matically; the tools will be engaged
and stopped.
• The machine must be switched off.
• Position the squeegee (2) below the
squeegee holder (1).
• Push the squeegee holder down-
wards to latch onto the squeegee.
• Firmly attach both suction hoses to the sockets of the
squeegee.
• The machine must be switched off.
• Open the tank lid.
• Put the fresh water tank (Flextank) onto the provided fix-
ture.
• Take the dosing cup from the fresh water tank (Flextank).
• Fill water into the fresh water tank
(Flextank).
The upper red marking indicates the
max. permissible filling level.
• Tilt the tank cover back to the original position.
-
0.5% 50ml for 10l of
water
200l 1l
1% 100 ml for 10l
of water
200l 2l
2% 200 ml for 10l
of water
200l 4l
3% 300 ml for 10l
of water
200l 6l
• Fill the dosing cup with a suitable product and pour the con-
tent into the fresh water tank. Repeat the procedure until
the required dosing is reached.
• When dosing is finished, the dosing cup will remain in the
tank.
