Perimeter Intersection
Perimeter Connector (PN22295, 2 legs removed in field)
1/4”-20 Screw (PN23077)
1/4” Lock Washer (PN23078)
Perimeter & Structural Tee/MR Intersection
Perimeter Connector (PN22295, 1 leg removed in field)
1/4”-20 Screw (PN23077)
1/4” Lock Washer (PN23078)
