Tatung L7CMS User Manual

L7C SERIES LCD Monitor Service Manual (v1.0)
5
2.2 – Analog Inputs
Mode
No.
Mode Name
Resolution
H.Freq.(KHZ)
V.Freq.(HZ)
H. Polarity
V. Polarity
Pixel CLK
(MHZ)
1 VGA 60HZ
640*480
31.469
59.941
－
－
25.175
2 VGA 72HZ
640*480
37.804
72.81
－
－
31.5
3 VGA 75HZ
640*480
37.5
75.0
－
－
31.5
4 SVGA 56HZ
800*600
35.156
56.25
＋
＋
36.0
5 SVGA 60HZ
800*600
37.879
60.317
＋
＋
40.0
6 SVGA 72HZ
800*600
48.077
72.188
＋
＋
50.0
7 SVGA 75HZ
800*600
46.875
75.0
＋
＋
49.5
8 XGA 60HZ
1024*768
48.363
60.004
－
－
65.0
9 XGA 70HZ
1024*768
56.476
70.069
－
－
75.0
10 XGA 75HZ
1024*768
60.023
75.029
＋
＋
78.75
11 SXGA 60HZ
1280*1024
63.981
60.020
＋
＋
108
12 SXGA 75HZ
1280*1024
79.976
75.025
＋
＋
135
13 MAC SVGA
640*480
35.0
66.667
－
－
30.24
14 MAC SVGA
832*624
493725
74.550
－
－
57.283
15 US TEXT
720*400
31.469
70.087
－
＋
28.322
16 VGA 70HZ
640*350
31.469
70.087
＋
－
25.175
Note: The display is capable of going beyond these recommended modes.

Tatung L7CMS Specifications

General

Brand	Tatung
Model	L7CMS
Category	Monitor
Language	English
